Pipe Threading Tangential Chasers

Bolt Threading Tangential Chaser by Industrial Machinery Corporation

Bolt Threading Tangential Chaser by Industrial Machinery Corporation thumbnail

Review Pipe Threading Tangential Chasers for your component and the required production operation.

Prepare a job-specific equipment enquiry

IMC can review a configuration to cut external threads when a matched tangential chaser set is fitted to a compatible die head against your component requirements. Send a drawing or sample and state die-head make or model, chaser dimensions, workpiece material and thread designation. Distinguish the required operation from other stages in the workshop so the offer identifies the equipment actually needed.

Confirm the working configuration

The technical discussion should address chaser seating, cutting profile and the interface with the specified Lanco or other head. Ask for the included tool package and accessories to be identified against the drawing rather than relying only on a product name. Lanco type compatibility is model-specific; provide existing tooling dimensions rather than treating the name as a universal fit. Include the intended batch mix and how the workpiece will be loaded, supported and inspected.

Specify delivery and acceptance

Agree the component checks for a representative thread, required gauge fit and the condition of the cutting edges. Confirm the destination and available electrical supply, together with any packing, spare-tool or commissioning needs. Delivery and service terms should be agreed in the offer. Review the model data below and add the selected configuration and quantity to the Quote List so those options accompany the enquiry.

Information to send with your enquiry

Die-head make or model
Chaser dimensions
Workpiece material and thread designation

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Chaser Size

5" x 2.1/4"(Set of 6 Pcs)

5" x 2.1/4" (Set of 4 Pcs)

4" x 1.1/4"(Set of 4 Pcs)

4" x 1.3/64 (Set of 4 Pcs)

3" X 1.3/64 (Set of 4 Pcs)

Quantity Required

Expected Price

Thread Type

Purchase

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

Since 2011, when Industrial Machinery Corporation came into being, we have been concentrating only on one major point and i.e. manufacturing and supplying the best of industrial machines for our clients. Since then only, our motto has been to satisfy the client with the products rather than roping them with flowery words and looting money big time from them. We have some of the toughest characteristics inbuilt into our character which enables us to behold our position of being the best in the world. Qualities of likable leadership, focused unity of purpose and direction, full involvement of people at all levels of association, fact-based decisions, and logical and regular evaluations of suitability, adequacy, and efficiency of the entire structure ensure the environment for continual improvement for the unit to achieve and maintain that environment and finally, the core management team have made sure that our hunger of producing best machine never ends at any cost. It is due to these qualities that we have become the most preferred as well as the recommended brand in the industry today and have been successfully handling the pressure mounted on us to continuously deliver the best in the business. Apart from our all industrial machine, we have a particular name as the leader in manufacturing Bolt Threading Tangential Chaser. The reason behind this is that our Bolt Threading Tangential Chaser meets all the safety parameters prevailing in the international market and has surpassed all the quality checks and tests every now and then. Our dedicated team works effortlessly and tirelessly over improving the quality of our Bolt Threading Tangential Chaser.

Following are the types of Bolt Threading Tangential Chaser that we specialize in making here at the industrial machinery corporation.

Thread cutting Tangential chaser
Pipe threading Tangential chaser
Bolt threading Tangential chaser
Rod threading Tangential chaser

Our Threading Tangential Chaser is fit to produce the thread of the following categories with exceptional capability and class.

BSP
BSPT
NPT
UNF
UNC
BSW

Frequently Asked Questions About Bolt Threading Tangential Chaser

Why discuss die-head type, material and thread form before ordering bolt threading tangential chaser?

Those details define the application that the equipment must accommodate. Identify the die head and chaser dimensions, together with the required thread and workpiece material. A sample or clear tool photograph is useful.

How do I build an enquiry for the bolt threading tangential chaser shown here?

Select the listed machine options, add the required quantity and attach your application notes. State die-head type, material and thread form, together with the intended output and delivery location, so the quotation addresses your actual production task.

What does the bolt threading tangential chaser do within a production setup?

Tangential chasers provide the cutting profile when fitted to a compatible threading die head. Its role should be considered alongside the preceding preparation and subsequent inspection or assembly steps. The technical table and working videos provide a starting point for that discussion.
